COMPATIBILITY:Detroit Diesel Series 60 and two cycle 92 engines. REPLACEMENT : Direct Replacement for J-35686-B, J-35686 & J-35686-A. Used on multiple Seal & Wear Sleeve Assemblies including 23516969 23513578 23513485 23518355. MATERIAL: High quality heavy duty steel with CNC processing and Zinc black electroplate, our product ensures excellent mechanical and physical properties — strong, corrosion resistant and durable in use. Best choice of motor parts. J-35686-B Front and Rear Wear Sleeve and Seal Installer for Detroit Diesel Series 60 and Two Cycle 92 Engines. Detroit Diesel Series 60 and two cycle 92 engines. APPLICATION & BENEFIT: This tool installs the front and rear crankshaft wear sleeves and seals. It eliminates lip flare on the wear sleeve and installs the seal properly without leakage. 100% SATISFACTION GUARANTEE: We aim to give our customers the best products and services. Fitment: For use on Detroit Diesel Series 60 and two cycle 92. Use on seal # 23516969 23513578 23513485 23518355. Feature: – For use on Detroit Diesel Series 60 and two cycle 92 – Similar to J-35686-B – Installs front crankshaft seal – Installs front crankshaft wear sleeve. Function: Install old seal p/n- 23513485 and new seal p/n- 23518355 front seals and p/n 23516969 & 23513578 rear seal and wear sleeve. J-35686-B Front and Rear Crankshaft Seal and Wear Sleeve Installer Alt. This tool is easier to use due to a simpler design. Protect your engine by preventing wear sleeve lip flare by using our low-priced but Quality installation tools. Installs the front and rear crankshaft wear sleeves and seals. It eliminates lip flare on the wear sleeve and installs the seal properly. For use on Detroit Diesel Series 60 and two cycle 92. Installs front crankshaft seal. Installs front crankshaft wear sleeve. Lubricate the rubber outer diameter of the oil seal with clean engine oil. Lubricate the gear case cover or flywheel housing bore with clean engine oil. Install two guide studs (J-35686-2) through the holes provided in the center guide assembly (J-35686-1) and into two of the tapped holes in the crankshaft 180 degrees apart. Tighten the guide studs. The base must be tight against the end of the crankshaft. Install the spacers to the center screw of the base. Slide the oil seal assembly over the installer base as far onto the crankshaft hub as possible. Slide collar with the stepped side contacting the seal. Slide the installer cup over the guide studs and installer base. Lubricate the center screw of the base with extreme pressure lubricant. Install the thrust bearing with the case side toward the installer cup and install the hex nut to the center screw of the base. Tighten the hex nut until the oil seal and wear sleeve are pressed into the flywheel housing or gear case cover. When the inside surface of the housing is seated firmly against the base and spacers the seal and sleeve are properly installed. 1 Center Guide Assembly (J-35686-1) 1 Spacer Plate 1 Installer Body (J-35686-4) 1 Thrust Bearing & J-35686-3 2 guide studs (J-35686-2) 2 Crankshaft Seal Installer Spacer (J-35686-20 / J-35686-10). J-35686-B Front and Rear Wear Sleeve Seal Installer. Single item or Kit. Detroit Diesel Series 60 and Two Cycle 92 Engines. Please list your special requests color, packages, etc. It is important that we know when your return is expected. We need this in case there are any issues during transit. Welcome to our store! We are a professional worldwide wholesale company, with our own factory located in China. We will reply your message within 24 hours Mon-Sat, and 48 hours on Sunday. We maintain high standards of excellence. Feedback is very important to us. Pls contact me first before you leave Neutral. I will do my best to solve the problem, thanks! Cat Cater pillar Tools. Chevy Chevrolet / Buick Tools. Dodge / Chrysler / Jeep. Toyota / lexus / Nissan Tools. Honda / Yamaha Tools. 6PC Valve Tappet Adjusting Tool Set for HONDA YAMAHA SUZUKI KAWASAKI MOTORCYCLES. Oil Filter Wrench Cap Removal Tool for Toyota Corolla Prius Scion Matrix 1.8L. Adjustable Boost Elbow Controller for 19942004 Dodge Cummins Turbo 2500/3500. 74mm Oil Filter Wrench Tool for Benz, VW Volkswagen, Audi, Porsche, Mazda and more. 27021 Stainless Steel Protector Skeg Guard For Mercury Mercuriser Alpha I 85-90. Skeg Guard 35-SS625 for Mercury Mariner Honda Yamaha Nissan Outboard Safe-Skeg. For Dodge Ram ISB 6.7 Holset HE300VG HE351VE Cummins Actuator Adapter 5347703H. Port Trim Ram Cylinder for Mercruiser Bravo 1 2 3 Replaces 98703A26 9B-121-02.
